Thread: Bad-Boy 92 inch 1952 Pan
-
05-09-2022 #401Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
This ^^ didn't work out all that well .. The gear was harder than a three day old biscuit .. Bout an hour of spinning only moved about .0002" of meat .. I'd be there till the cows came home ..
Reverted back to the 32-E Gen method of setting up the backlash ..
Gen bolts O.D. was shaved down .010" to allow the Gen some movement ..
Took two steel shims in order to have .002" backlash ...
Used pieces from both kits to do the looksee ...
____________________________________________
Won't be long till the cases are glued ...
Last edited by Dragstews; 05-11-2022 at 5:31 AM.
-
05-09-2022 #402Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
It might be a while yet ...
How bout this shit :x .... Went to get a tube of Permatex Anaerobic Gasket Maker to glue the cases with ...
Was in the parts store, got the glue and handed them my CC ...
They said it was denied ... WTF !!
There was over $800 in that account ... Went to the bank to find out what's going on ..
They said I've been hacked !!
Some dip-shit in Saudi Arabia maxed out my card buying Airline tickets ...
So .... Kinda looks like it might be awhile before I can buy glue ...
!! Bastards !! ... Drop a nuke on those M/F's and they will stop screwing up peoples lives ..
Five to Seven days ... New Card ..Last edited by Dragstews; 05-09-2022 at 6:03 PM.
-
05-09-2022 #403Senior Member
- Join Date
- May 2018
- Posts
- 881
That is fucked up. I really wish there were a way to reach through the screens and choke the living shit out of people like that.
-
05-09-2022 #404Senior Member
- Join Date
- Apr 2013
- Posts
- 9,825
That's why I have two credit cards since every few years some bot finds the number on one of them. It's inevitable.
-
05-09-2022 #405Senior Member
- Join Date
- Oct 2016
- Posts
- 2,436
That's messed up folks. We have been so damn lucky, but I am pretty cautious and use Paypal whenever possible on-line.
-
05-09-2022 #406Senior Member
- Join Date
- Oct 2012
- Posts
- 1,872
I went to my credit union to protest a charge last week and he had my card cancelled and gave me a new card in about 15 minutes. I'd be screaming like a stuck hog if they made me wait five to seven days.
Originally Posted by Dragstews
Dusty
-
05-10-2022 #407Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
I got a new tube of glue .. Yippy
The Boys at Advance Auto gave me a open invoice to pay.
Once the bank gets this ordeal (5 to 7 days) straighten out I'll catch up with em ...
Mighty nice of them to do that ..
Now that the cases are glued & nailed together, more checks are in the works ..
Good as Gold here ..
Piston will be running up and down the bore straight as a string ...
In need of a few small parts and the cam chest will be locked, crocked and ready to rock !!
Oil pump has good finger spin ..
______________________________________________
Looks like a 48 to me ...
Also see a few more parts that will be needed ..
1) Pushrod tube covers, if you reuse the EL covers the clips will be to short .. FL clips will be needed ..
2) Headbolts ... I would strongly suggest 12 point heads ... Makes life easier working with em.
3) Thick D-ring Pan cover bolts ..
4) Intake clamps ... I'd use "FNA Custom Cycle" Tite seal with the VT conversion rings ..
5) 3/8" Carb spacer from S&S
And valves and springs ..
Heads came with what VT loaded them with ... Nothing to write home about ..
They packed the springs for a max valve lift of .425".
The L-51 cam has a .533" valve lift ..
My pick for replacing the wind from the east stuff would be KPMI "Black Diamond" valves and their Lightweight Racing Spring kit which has a max valve lift at .600"
You could reuse the valves that came with the VT heads, but not the springs ...
__________________________________________________
Kinda a wee bit "Plain Jane" sitting next to the 52 ... Ain't it .. ??
..
..
Last edited by Dragstews; 05-11-2022 at 6:23 AM.
-
05-11-2022 #408Senior Member
- Join Date
- Apr 2013
- Posts
- 9,825
Plain is how I like 'em on the outside (which also means a lot less upkeep).
Order parts per the above list.Last edited by farmall; 05-11-2022 at 8:55 AM.
-
05-11-2022 #409Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
I hear ya, the owner of the 52 keeps asking me how will he keep the shine shinning ...?? Originally Posted by farmall
Told him to become a Mormon !! (At least marry 6)
Last edited by Dragstews; 05-11-2022 at 5:22 PM.
-
05-11-2022 #410Senior Member
- Join Date
- Oct 2016
- Posts
- 2,436
This is how I did it in the old days... Originally Posted by Dragstews
-
05-11-2022 #411Senior Member
- Join Date
- May 2018
- Posts
- 881
Now THAT's funny as hell!! Originally Posted by Dragstews
I hear ya, the owner of the 52 keeps asking me how will he keep the shine shinning ...??
Told him to become a Mormon !! (At least marry 6)
-
05-12-2022 #412Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
Should the jugs be made to look new again, Fellows .. ??
Had many coats laid down over the years ..
So much build up that it was flaking off in a lot of areas ..
Could also repair a few broken fins while I'm at it ..
Your call Boss ...Last edited by Dragstews; 05-12-2022 at 6:22 PM.
-
05-12-2022 #413Senior Member
- Join Date
- May 2018
- Posts
- 881
Do it!
-
05-13-2022 #414Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
Ok .... Ya talked me into it .. Originally Posted by rockman96
(Didn't take much talking, did it ?) ..
First off is to get the pressure pot back on line ... Been awhile since it has seen any action ..
Did a little stripping with a air file ..
Do a nice enough job on the fin repair, might throw on a super nice, long lasting finish ... ??
(If not a rattle can will do)
-
05-13-2022 #415Senior Member
- Join Date
- Apr 2013
- Posts
- 9,825
Powder coat the things. After this much hassle the longer it goes untouched the better!
-
05-13-2022 #416Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
This is how the "Hotcoat Powder Coat Jet Black" will look ...
High Gloss Jet Black powder provides a smooth, glossy finish.
-
05-14-2022 #417Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
Wasn't after steel wheels for the sand blaster, but it was all that Ace Hardware had in stock ...
Really wasn't wanting to use the sand blaster in the first place ... Tried to get the paint off of the jugs by bead blasting ...
But the paint was coming off super slow .... And down inside the fins was almost a no-go at all ..
Got a 50lb bag of sand ... Will drag the sand blaster out the back door and have at it ... (Tis a PITA doing it out in the Florida Hot Sun)
Hoping one bag will do both jugs .. ?? Soon to find out ..
That's one ... ^^
The other jug has no broken fins ...
Lets see if there is enough sand left in the pot to do it .. ??
(Ya known, I'd almost be willing to get bitch slapped instead of sand blasting out in the heat)
But, I'm halfway there now ...
(I know, quit my bitching and ....... )
Front jug is done, time for a snow cone !!
Still in need of a donor jug to rob some fins from...
Hadn't heard from my Buddy just yet ... ??
Cool ... He just called me ...
Said he has some 900 Sportie jugs ...Last edited by Dragstews; 05-14-2022 at 11:13 PM.
-
05-14-2022 #418Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
Black it is ...
That will make the new chrome pushrod covers pop .. !!
No-mo ugly jugs ... !!Last edited by Dragstews; 05-14-2022 at 4:24 PM.
-
05-14-2022 #419Senior Member
- Join Date
- May 2018
- Posts
- 881
Looking good!!
-
05-14-2022 #420Senior Member
- Join Date
- Sep 2010
- Posts
- 13,490
Better than a rattle can ... Powder Coat is some tough stuff ..
Might last longer than H.G. Wells' time machine ...
... /// https://youtu.be/SSqqwv86Pts \\\ ...Last edited by Dragstews; 05-14-2022 at 7:50 PM.
